Kody diagnostyczne i serwisowe Bobcat - lista błędów i rozwiązań
Diagnostyka Bobcat - odczyt i interpretacja kodów usterek
Maszyny Bobcat wyposażone są w system elektroniczny, który monitoruje parametry pracy i zgłasza wszelkie nieprawidłowości w formie kodów błędów. Dzięki temu operator może szybko zidentyfikować problem i podjąć odpowiednie działania, aby uniknąć awarii lub dłuższego przestoju.
⚠️ Uwaga: Zanim przystąpisz do naprawy lub serwisu, zawsze skonsultuj się z Instrukcją Obsługi i Konserwacji swojej maszyny Bobcat.
Obsługiwane maszyny - zakres kodów diagnostycznych Bobcat:
Ładowarki serii M: od S450 do S850, od T450 do T870
Ładowarki serii R: od S60 do S70, od T60 do T70
Minikoparki serii M: od E26 do E85
Koparki E145 i E165
Ładowarki przegubowe kompaktowe (SAL)
Maszyny wielofunkcyjne Toolcat
Ładowarki kołowe kompaktowe
Ładowarki teleskopowe Bobcat
Osprzęt Bobcat
Diagnostyka silników Bobcat:
Silniki Bobcat V1 (ECU DELPHI)
Silniki Bobcat V2 (ECU BOSCH)
Silniki Bobcat D34 (DCU)
Specjalizujemy się w diagnostyce Bobcat, naprawach i optymalizacji pracy maszyn. Pomagamy zarówno w szybkim rozwiązywaniu problemów z kodami błędów, jak i w zapobieganiu przyszłym usterkom.
Bobcat Diagnostic Service Codes provide operators with a clear way to identify and troubleshoot machine issues. Covering loaders, excavators, telehandlers, and engines (Delphi, Bosch, DCU), these codes improve efficiency and minimize downtime. If you need help interpreting a fault code, our team can assist with diagnostics, repair, and machine optimization.
| Code | Product | Description | ||||||
| W0176 | M-Series Loader | Input Selection Flipped While Operating | ||||||
| W0321 | M-Series Loader | Battery Voltage Out of Range High | ||||||
| W0321 | Telehandler | Battery Voltage OOR High | ||||||
| W0322 | Telehandler | Battery Voltage OOR Low | ||||||
| W0322 | M-Series Loader | Battery Voltage Out of Range Low | ||||||
| W0521 | M-Series Loader | Lift Spool Position Sensor Out of Range High | ||||||
| W0522 | M-Series Loader | Lift Spool Position Sensor Out of Range Low | ||||||
| Code | Product | Description | ||||||
| W0524 | M-Series Loader | Lift Spool Position Sensor Not in Neutral | ||||||
| W0525 | M-Series Loader | Lift Spool Position Sensor Unresponsive | ||||||
| W0595 | M-Series Loader | Lift Spool Position Sensor Inverted Movement | ||||||
| W0621 | M-Series Loader | Tilt Spool Position Sensor Out of Range High | ||||||
| W0622 | M-Series Loader | Tilt Spool Position Sensor Out of Range Low | ||||||
| W0624 | M-Series Loader | Tilt Spool Position Sensor Not in Neutral | ||||||
| W0625 | M-Series Loader | Tilt Spool Position Sensor Unresponsive | ||||||
| W0695 | M-Series Loader | Tilt Spool Position Sensor Inverted Movement | ||||||
| W0721 | Telehandler | Hydraulic Oil Temperature OOR High | ||||||
| W0722 | Telehandler | Hydraulic Oil Temperature OOR Low | ||||||
| W1005 | M-Series Loader | Lift Base Solenoid Short to Battery | ||||||
| W1005 | Telehandler | PVG32 Lift Up/Down valve Short to Battery | ||||||
| W1006 | Telehandler | PVG32 Lift Up/Down Valve Short to Ground | ||||||
| W1006 | M-Series Loader | Lift Base Solenoid Short to Ground | ||||||
| W1007 | Telehandler | PVG32 Lift Up/Down Valve Open circuit | ||||||
| W1007 | M-Series Loader | Lift Base Solenoid Open Circuit | ||||||
| W1028 | Telehandler | PVG32 Lift Up/Down Valve in error. From mainvalve diagnostic | ||||||
| W1032 | M-Series Loader | Lift Base Solenoid Overcurrent | ||||||
| W1105 | Telehandler | PVG32 Tilt Valve Short to Battery | ||||||
| W1105 | M-Series Loader | Lift Rod Solenoid Short to Battery | ||||||
| W1106 | M-Series Loader | Lift Rod Solenoid Short to Ground | ||||||
| W1106 | Telehandler | PVG32 Tilt Valve Short to Ground | ||||||
| W1107 | M-Series Loader | Lift Rod Solenoid Open Circuit | ||||||
| W1107 | Telehandler | PVG32 Tilt Valve Open circuit | ||||||
| W1128 | Telehandler | PVG32 Tilt Valve in error,From mainvalve diagnostic | ||||||
| W1132 | M-Series Loader | Lift Rod Solenoid Overcurrent | ||||||
| W1205 | M-Series Loader | Tilt Base Solenoid Short to Battery | ||||||
| W1205 | Telehandler | PVG32 Extend/Retract Valve Short to Battery | ||||||
| W1206 | M-Series Loader | Tilt Base Solenoid Short to Ground | ||||||
| W1206 | Telehandler | PVG32 Extend/Retract Valve Short to Ground | ||||||
| W1207 | M-Series Loader | Tilt Base Solenoid Open Circuit | ||||||
| W1207 | Telehandler | PVG32 Extend/Retract Valve Open circuit | ||||||
| W1228 | Telehandler | PVG32 Extend/Retract Valve in errorFrom mainvalve diagnostic | ||||||
| W1232 | M-Series Loader | Tilt Base Solenoid Overcurrent | ||||||
| W1305 | M-Series Loader | Tilt Rod Solenoid Short to Battery | ||||||
| W1305 | Telehandler | PVG32 Auxiliary Valve Short to Battery | ||||||
| W1306 | Telehandler | PVG32 Auxiliary valve Short to Ground | ||||||
| W1306 | M-Series Loader | Tilt Rod Solenoid Short to Ground | ||||||
| W1307 | M-Series Loader | Tilt Rod Solenoid Open Circuit | ||||||
| W1307 | Telehandler | PVG32 Auxiliary valve Open circuit | ||||||
| W1328 | Telehandler | PVG32 Auxiliary Valve in error,From mainvalve diagnostic | ||||||
| W1332 | M-Series Loader | Tilt Rod Solenoid Overcurrent | ||||||
| W1405 | Telehandler | PVG32 Frame Leveling Valve Short to Battery | ||||||
| W1406 | Telehandler | PVG32 Frame Leveling Valve Short to Ground | ||||||
| W1407 | Telehandler | PVG32 Frame Leveling Valve Open circuit | ||||||
| W1428 | Telehandler | PVG32 Frame Leveling Valve in errorFrom mainvalve diagnostic | ||||||
| W1505 | M-Series Loader | Pedal Lock Short to Battery | ||||||
| W1506 | M-Series Loader | Pedal Lock Short to Ground | ||||||
| W1507 | M-Series Loader | Pedal Lock Open Circuit | ||||||
| W1605 | M-Series Loader | Handle Lock Short to Battery | ||||||
| W1606 | M-Series Loader | Handle Lock Short to Ground | ||||||
| W1607 | M-Series Loader | Handle Lock Open Circuit | ||||||
| Code | Product | Description | ||||||
| W1824 | Telehandler | Frame Leveling potentiometer Out of neutral | ||||||
| W2021 | M-Series Loader | Lift Handle Sensor Out of Range High | ||||||
| W2022 | M-Series Loader | Lift Handle Sensor Out of Range Low | ||||||
| W2121 | M-Series Loader | Lift Pedal Sensor Out of Range High | ||||||
| W2122 | M-Series Loader | Lift Pedal Sensor Out of Range Low | ||||||
| W2205 | Telehandler | Lift Up Output Short To Battery | ||||||
| W2206 | Telehandler | Lift Up Output Short To Ground | ||||||
| W2207 | Telehandler | Lift Up Output Open Circuit | ||||||
| W2221 | M-Series Loader | Tilt Handle Sensor Out of Range High | ||||||
| W2222 | M-Series Loader | Tilt Handle Sensor Out of Range Low | ||||||
| W2232 | Telehandler | Lift Up Output Overcurrent | ||||||
| W2299 | Telehandler | Lift Up Solenoid Calibration Required | ||||||
| W2299 | Telehandler | Lift Up Coil Calibration required | ||||||
| W2305 | Telehandler | Lift Down Output Short To Battery | ||||||
| W2306 | Telehandler | Lift Down Output Short To Ground | ||||||
| W2307 | Telehandler | Lift Down Output Open Circuit | ||||||
| W2321 | M-Series Loader | Tilt Pedal Sensor Out of Range High | ||||||
| W2322 | M-Series Loader | Tilt Pedal Sensor Out of Range Low | ||||||
| W2332 | Telehandler | Lift Down Output Overcurrent | ||||||
| W2399 | Telehandler | Lift Down Coil Calibration required | ||||||
| W2399 | Telehandler | Lift Down Solenoid Calibration Required | ||||||
| W2405 | Telehandler | Tilt Out Output Short To Battery | ||||||
| W2406 | Telehandler | Tilt Out Output Short To Ground | ||||||
| W2407 | Telehandler | Tilt Out Output Open Circuit | ||||||
| W2432 | Telehandler | Tilt Out Output Overcurrent | ||||||
| W2505 | Telehandler | Tilt Back Output Short To Battery | ||||||
| W2506 | Telehandler | Tilt Back Output Short To Ground | ||||||
| W2507 | Telehandler | Tilt Back Output Open Circuit | ||||||
| W2532 | Telehandler | Tilt Back Output Overcurrent | ||||||
| W2605 | Telehandler | Extend Output Short To Battery | ||||||
| W2606 | Telehandler | Extend Output Short To Ground | ||||||
| W2607 | Telehandler | Extend Output Open Circuit | ||||||
| W2632 | Telehandler | Extend Output Overcurrent | ||||||
| W2705 | Telehandler | Retract Output Short To Battery | ||||||
| W2706 | Telehandler | Retract Output Short To Ground | ||||||
| W2707 | Telehandler | Retract Output Open Circuit | ||||||
| W2732 | Telehandler | Retract Output Overcurrent | ||||||
| W2824 | M-Series Loader | Lift Input Not in Neutral | ||||||
| W2924 | M-Series Loader | Tilt Input Not in Neutral | ||||||
| W3128 | M-Series Loader | Interrupted Power Failure | ||||||
| W3223 | M-Series Loader | ACS Calibration required | ||||||
| W3223 | Telehandler | Programming or constant data invalid | ||||||
| W3224 | M-Series Loader | ACS Calibration Performed | ||||||
| W3225 | M-Series Loader | ACS (AHC) Calibration Failed | ||||||
| W3228 | Telehandler | Controller failure | ||||||
| W3231 | M-Series Loader | ACS/AHC Tilt actuator fault | ||||||
| W3232 | M-Series Loader | AHC Tilt actuator wiring fault | ||||||
| W3233 | M-Series Loader | AHC Tilt handle wiring fault | ||||||
| W3234 | M-Series Loader | ACS/AHC Tilt actuator not in neutral | ||||||
| W3235 | M-Series Loader | ACS/AHC Tilt handle not in neutral | ||||||
| W3236 | M-Series Loader | ACS/AHC Lift actuator fault | ||||||
| W3237 | M-Series Loader | AHC Lift actuator wiring fault | ||||||
| Code | Product | Description | ||||||
| W3238 | M-Series Loader | AHC Lift handle wiring fault | ||||||
| W3239 | M-Series Loader | ACS/AHC Lift actuator not in neutral | ||||||
| W3240 | M-Series Loader | ACS/AHC Lift handle not in neutral | ||||||
| W3241 | M-Series Loader | AHC No communication | ||||||
| W3249 | M-Series Loader | ACS Lift actuator short to ground | ||||||
| W3250 | M-Series Loader | ACS Tilt actuator short to ground | ||||||
| W3251 | M-Series Loader | ACS Lift actuator short to battery | ||||||
| W3252 | M-Series Loader | ACS Tilt actuator short to battery | ||||||
| W3253 | M-Series Loader | ACS Lift handle/pedal short to ground | ||||||
| W3254 | M-Series Loader | ACS Tilt handle/pedal short to ground | ||||||
| W3255 | M-Series Loader | ACS Lift handle/pedal short to battery | ||||||
| W3256 | M-Series Loader | ACS Tilt handle/pedal short to battery | ||||||
| W3257 | M-Series Loader | ACS Lift actuator reduced performance | ||||||
| W3258 | M-Series Loader | ACS Tilt actuator reduced performance | ||||||
| W3259 | M-Series Loader | ACS Lift actuator wrong direction | ||||||
| W3260 | M-Series Loader | ACS Tilt actuator wrong direction | ||||||
| W3261 | M-Series Loader | ACS Handle lock short to ground | ||||||
| W3262 | M-Series Loader | ACS Handle lock short to battery | ||||||
| W3263 | M-Series Loader | ACS Pedal lock short to ground | ||||||
