Diagnostyka Bobcat - odczyt i interpretacja kodów usterek
Maszyny Bobcat wyposażone są w system elektroniczny, który monitoruje parametry pracy i zgłasza wszelkie nieprawidłowości w formie kodów błędów. Dzięki temu operator może szybko zidentyfikować problem i podjąć odpowiednie działania, aby uniknąć awarii lub dłuższego przestoju.
⚠️ Uwaga: Zanim przystąpisz do naprawy lub serwisu, zawsze skonsultuj się z Instrukcją Obsługi i Konserwacji swojej maszyny Bobcat.
Obsługiwane maszyny - zakres kodów diagnostycznych Bobcat:
Ładowarki serii M: od S450 do S850, od T450 do T870
Ładowarki serii R: od S60 do S70, od T60 do T70
Minikoparki serii M: od E26 do E85
Koparki E145 i E165
Ładowarki przegubowe kompaktowe (SAL)
Maszyny wielofunkcyjne Toolcat
Ładowarki kołowe kompaktowe
Ładowarki teleskopowe Bobcat
Osprzęt Bobcat
Diagnostyka silników Bobcat:
Silniki Bobcat V1 (ECU DELPHI)
Silniki Bobcat V2 (ECU BOSCH)
Silniki Bobcat D34 (DCU)
Specjalizujemy się w diagnostyce Bobcat, naprawach i optymalizacji pracy maszyn. Pomagamy zarówno w szybkim rozwiązywaniu problemów z kodami błędów, jak i w zapobieganiu przyszłym usterkom.
Bobcat Diagnostic Service Codes provide operators with a clear way to identify and troubleshoot machine issues. Covering loaders, excavators, telehandlers, and engines (Delphi, Bosch, DCU), these codes improve efficiency and minimize downtime. If you need help interpreting a fault code, our team can assist with diagnostics, repair, and machine optimization.
| Code | Product | Description | ||||||
| M7203 | M-Series Loader | Electric Fan Relay Error Off | ||||||
| M7304 | M-Series Loader | Remote Control No Communication | ||||||
| M7316 | M-Series Loader | Remote Control Not Connected | ||||||
| M7423 | M-Series Loader | Main Controller Not Programmed | ||||||
| M7472 | M-Series Excavator | Main Controller Software Incompatible | ||||||
| M7473 | M-Series Excavator | Main Controller Software Outdated | ||||||
| M7497 | M-Series Loader | Main Controller Software Updated | ||||||
| M7497 | M-Series Excavator | Main Controller Controller Programmed | ||||||
| M7504 | M-Series Loader | Drive No Communication | ||||||
| M7604 | M-Series Excavator | Standard Display Panel No Communication | ||||||
| M7604 | M-Series Loader | Left Display Panel No Communication | ||||||
| M7748 | M-Series Loader | Key Switch Multiple | ||||||
| M7748 | Telehandler | Multiple key on active (service tool & keyswitch) | ||||||
| M7839 | M-Series Loader | Hourmeter Changed | ||||||
| M7902 | M-Series Loader | Forestry Door Closed | ||||||
| M7974 | M-Series Loader | Door Open | ||||||
| M8004 | M-Series Excavator | Cooling Fan Controller No Communication | ||||||
| M8005 | M-Series Excavator | Cooling Fan Short To Battery | ||||||
| M8006 | M-Series Excavator | Cooling Fan Short To Ground | ||||||
| M8021 | Telehandler | Throttle pedal analog signal Out Of Range High | ||||||
| M8021 | M-Series Excavator | Cooling Fan Out Of Range High | ||||||
| M8022 | Telehandler | Throttle pedal analog signal Out Of Range Low | ||||||
| M8022 | M-Series Excavator | Cooling Fan Out Of Range Low | ||||||
| M8025 | M-Series Excavator | Cooling Fan Unresponsive | ||||||
| M8027 | M-Series Excavator | Cooling Fan CAN Error | ||||||
| M8028 | Telehandler | Throttle pedal in error.(redundancy error) | ||||||
| M8028 | M-Series Excavator | Cooling Fan Failure | ||||||
| M8029 | M-Series Excavator | Cooling Fan Wiring Fault | ||||||
| M8030 | M-Series Excavator | Cooling Fan Controller Fault | ||||||
| M8128 | Telehandler | Wrong DEF Sensor detected | ||||||
| M8228 | M-Series Loader | AdBlue/DEF Sensor Mismatch | ||||||
| M8228 | Telehandler | Inhibit DESOX/REGEN switch in failure | ||||||
| M8302 | M-Series Excavator | Wait to Start Lamp Error On | ||||||
| M8303 | M-Series Excavator | Wait to Start Lamp Error Off | ||||||
| M8328 | Telehandler | Force DESOX/REGEN Switch in failure | ||||||
| Code | Product | Description | ||||||
| M8402 | M-Series Loader | DESOX Service Requested | ||||||
| M8450 | Telehandler | DESOX/REGEN requested but inhibited | ||||||
| M8450 | M-Series Loader | DeSox Required but Inhibited | ||||||
| M8541 | M-Series Loader | DPF Automatic Regeneration Active | ||||||
| M8542 | M-Series Loader | DPF Automatic Regeneration Active | ||||||
| M8543 | M-Series Loader | DPF Regeneration Required | ||||||
| M8551 | M-Series Loader | DPF Regeneration NeededInhibit Active | ||||||
| M8552 | M-Series Loader | DPF Regeneration Needed - Inhibit Active | ||||||
| M8553 | M-Series Loader | DPF Remote Parked Regeneration Required - Remote Regeneration Kit Required | ||||||
| M8554 | M-Series Loader | DPF Service Regeneration Required - Contact Bobcat Dealer | ||||||
| M8555 | M-Series Loader | DPF Service Required | ||||||
| M8560 | M-Series Loader | DPF Service Regeneration Active | ||||||
| M8561 | M-Series Loader | DPF Service Regeneration Active | ||||||
| M8562 | M-Series Loader | DPF Service Regeneration Active | ||||||
| M8563 | M-Series Loader | DPF Service Regeneration Active | ||||||
| M8564 | M-Series Loader | DPF Service Regeneration Active | ||||||
| M8602 | Telehandler | Receiver input Error On | ||||||
| M8615 | M-Series Loader | Engine Speed Derate Shutdown | ||||||
| M8615 | M-Series Excavator | Engine Speed Derate In Shutdown | ||||||
| M8625 | M-Series Loader | Engine Speed Derate Unresponsive | ||||||
| M8703 | Telehandler | Attachment run input Error off | ||||||
| M8715 | M-Series Loader | Torque Derate Shutdown | ||||||
| M8725 | M-Series Loader | Torque Derate Unresponsive | ||||||
| M8804 | M-Series Loader | Telematics Not Connected | ||||||
| M8848 | Telehandler | Selection mode switch Multiple | ||||||
| M8928 | Telehandler | ECO Mode switch In error | ||||||
| M9111 | M-Series Excavator | Fuel Filter Extremely Plugged | ||||||
| M9117 | M-Series Excavator | Fuel Filter Plugged | ||||||
| M9144 | M-Series Excavator | Fuel Filter Derate Level 1 | ||||||
| M9145 | M-Series Excavator | Fuel Filter Derate Level 2 | ||||||
| M9202 | M-Series Excavator | Fuel Lift Pump Error On | ||||||
| M9203 | M-Series Excavator | Fuel Lift Pump Error Off | ||||||
| M9287 | M-Series Excavator | Fuel Pump Failure Time Exceeded | ||||||
| M9309 | M-Series Excavator | Fuel Pressure Low | ||||||
| M9314 | M-Series Excavator | Fuel Pressure Extremely Low | ||||||
| M9321 | M-Series Excavator | Fuel Pressure Out Of Range High | ||||||
| M9322 | M-Series Excavator | Fuel Pressure Out Of Range Low | ||||||
| M9344 | M-Series Excavator | Fuel Pressure Derate Level 1 | ||||||
| M9604 | Telehandler | Single Keypad No Communication | ||||||
| M9701 | M-Series Loader | Turbo Prime Sequence Active | ||||||
| M9704 | Telehandler | Primary Keypad No Communication | ||||||
| M9804 | Telehandler | Secondary Keypad No Communication | ||||||
| M9999 | Telehandler | Bad Constant Data table | ||||||
