Kody diagnostyczne i serwisowe Bobcat - lista błędów i rozwiązań
Diagnostyka Bobcat - odczyt i interpretacja kodów usterek
Maszyny Bobcat wyposażone są w system elektroniczny, który monitoruje parametry pracy i zgłasza wszelkie nieprawidłowości w formie kodów błędów. Dzięki temu operator może szybko zidentyfikować problem i podjąć odpowiednie działania, aby uniknąć awarii lub dłuższego przestoju.
⚠️ Uwaga: Zanim przystąpisz do naprawy lub serwisu, zawsze skonsultuj się z Instrukcją Obsługi i Konserwacji swojej maszyny Bobcat.
Obsługiwane maszyny - zakres kodów diagnostycznych Bobcat:
Ładowarki serii M: od S450 do S850, od T450 do T870
Ładowarki serii R: od S60 do S70, od T60 do T70
Minikoparki serii M: od E26 do E85
Koparki E145 i E165
Ładowarki przegubowe kompaktowe (SAL)
Maszyny wielofunkcyjne Toolcat
Ładowarki kołowe kompaktowe
Ładowarki teleskopowe Bobcat
Osprzęt Bobcat
Diagnostyka silników Bobcat:
Silniki Bobcat V1 (ECU DELPHI)
Silniki Bobcat V2 (ECU BOSCH)
Silniki Bobcat D34 (DCU)
Specjalizujemy się w diagnostyce Bobcat, naprawach i optymalizacji pracy maszyn. Pomagamy zarówno w szybkim rozwiązywaniu problemów z kodami błędów, jak i w zapobieganiu przyszłym usterkom.
Bobcat Diagnostic Service Codes provide operators with a clear way to identify and troubleshoot machine issues. Covering loaders, excavators, telehandlers, and engines (Delphi, Bosch, DCU), these codes improve efficiency and minimize downtime. If you need help interpreting a fault code, our team can assist with diagnostics, repair, and machine optimization.
| Code | Product | Description | ||||||
| M4510 | M-Series Loader | Water In Fuel Too High | ||||||
| M4511 | M-Series Loader | Water In Fuel Extremely High | ||||||
| M4521 | M-Series Loader | Water In Fuel Sensor Out of Range High | ||||||
| M4522 | M-Series Loader | Water In Fuel Sensor Out of Range Low | ||||||
| M4530 | M-Series Loader | Water In Fuel Sensor Fault | ||||||
| M4621 | M-Series Excavator | 5 Volt Sensor Supply Out Of Range High | ||||||
| M4621 | M-Series Loader | 5V Sensor Supply Out of Range High | ||||||
| M4622 | M-Series Loader | 5V Sensor Supply Out of Range Low | ||||||
| M4622 | M-Series Excavator | 5 Volt Sensor Supply Out Of Range Low | ||||||
| Code | Product | Description | ||||||
| M4721 | M-Series Excavator | 8 Volt Sensor Supply Out Of Range High | ||||||
| M4721 | M-Series Loader | 8V Sensor Supply Out of Range High | ||||||
| M4721 | Telehandler | Sensor Supply OORH | ||||||
| M4722 | Telehandler | Sensor Supply OORL | ||||||
| M4722 | M-Series Excavator | 8 Volt Sensor Supply Out Of Range Low | ||||||
| M4722 | M-Series Loader | 8V Sensor Supply Out of Range Low | ||||||
| M4802 | M-Series Loader | Front Light Relay Error On | ||||||
| M4803 | M-Series Loader | Front Light Relay Error Off | ||||||
| M4805 | Telehandler | Worklights output Error On | ||||||
| M4806 | Telehandler | Worklights output Error Off | ||||||
| M4902 | Telehandler | Blue lights Output Short To Battery or Open Circuit | ||||||
| M4902 | M-Series Loader | Rear Light Relay Error On | ||||||
| M4903 | M-Series Loader | Rear Light Relay Error Off | ||||||
| M4903 | Telehandler | Blue lights Output Short To Ground | ||||||
| M5002 | M-Series Loader | Front Light Output Error On | ||||||
| M5003 | M-Series Loader | Front Light Output Error Off | ||||||
| M5005 | Telehandler | Front Worklights Output Short to Battery | ||||||
| M5006 | Telehandler | Front Worklights Output Short to Ground | ||||||
| M5007 | Telehandler | Front Worklights Output Open Circuit | ||||||
| M5007 | M-Series Loader | Front Light Output Open Circuit | ||||||
| M5028 | M-Series Loader | Front Light Output Failure | ||||||
| M5102 | Telehandler | Rear Worklights Short To Battery or Open Circuit | ||||||
| M5102 | M-Series Loader | Rear Light Output Error On | ||||||
| M5103 | M-Series Loader | Rear Light Output Error Off | ||||||
| M5103 | Telehandler | Rear Worklights Output Short To Ground | ||||||
| M5107 | M-Series Loader | Rear Light Output Open Circuit | ||||||
| M5128 | M-Series Loader | Rear Light Output Failure | ||||||
| M5202 | M-Series Loader | Press to Operate Switch Error On | ||||||
| M5205 | M-Series Excavator | Offset Base Solenoid Short To Battery | ||||||
| M5205 | Telehandler | Electronic Battery Disconnect Output Open circuit or Short To Battery | ||||||
| M5206 | M-Series Excavator | Offset Base Solenoid Short To Ground | ||||||
| M5206 | Telehandler | Electronic Battery Disconnect Output Short To Ground | ||||||
| M5207 | Telehandler | Electronic Battery Disconnect Output Open circuit | ||||||
| M5207 | M-Series Excavator | Offset Base Solenoid Open Circuit | ||||||
| M5221 | M-Series Loader | Press to Operate Switch Out of Range High | ||||||
| M5222 | M-Series Loader | Press to Operate Switch Out of Range Low | ||||||
| M5232 | M-Series Excavator | Offset Base Solenoid Overcurrent | ||||||
| M5302 | Telehandler | Electronic Battery Disconnect stucked | ||||||
| M5303 | Telehandler | Electronic Battery Disconnect open error (unstucked) | ||||||
| M5305 | M-Series Loader | Press to Operate Light Short to Battery | ||||||
| M5305 | M-Series Excavator | Offset Rod Solenoid Error On | ||||||
| M5306 | M-Series Excavator | Offset Rod Solenoid Short To Ground | ||||||
| M5306 | M-Series Loader | Press to Operate Light Short to Ground | ||||||
| M5307 | M-Series Excavator | Offset Rod Solenoid Open Circuit | ||||||
| M5332 | M-Series Excavator | Offset Rod Solenoid Overcurrent | ||||||
| M5405 | M-Series Loader | Spool Lock 2 Short to Battery | ||||||
| M5406 | M-Series Loader | Spool Lock 2 Short to Ground | ||||||
| M5407 | M-Series Loader | Spool Lock 2 Open Circuit | ||||||
| M5421 | M-Series Excavator | Offset Control Switch Out Of Range High | ||||||
| M5422 | M-Series Excavator | Offset Control Switch Out Of Range Low | ||||||
| M5424 | M-Series Excavator | Offset Control Switch Out Of Neutral | ||||||
| M5432 | M-Series Loader | Spool Lock 2 Overcurrent | ||||||
| Code | Product | Description | ||||||
| M5505 | M-Series Excavator | Auxiliary Base Solenoid Short To Battery | ||||||
| M5506 | M-Series Excavator | Auxiliary Base Solenoid Short To Ground | ||||||
| M5507 | M-Series Excavator | Auxiliary Base Solenoid Open Circuit | ||||||
| M5532 | M-Series Excavator | Auxiliary Base Solenoid Overcurrent | ||||||
| M5605 | M-Series Excavator | Auxiliary Rod Solenoid Short To Battery | ||||||
| M5606 | M-Series Excavator | Auxiliary Rod Solenoid Short To Ground | ||||||
| M5607 | M-Series Excavator | Auxiliary Rod Solenoid Open Circuit | ||||||
| M5632 | M-Series Excavator | Auxiliary Rod Solenoid Overcurrent | ||||||
| M5721 | M-Series Excavator | Auxiliary Control Switch Out Of Range High | ||||||
| M5722 | M-Series Excavator | Auxiliary Control Switch Out Of Range Low | ||||||
| M5724 | M-Series Excavator | Auxiliary Control Switch Out Of Neutral | ||||||
| M5810 | M-Series Loader | Fuel Temperature High | ||||||
| M5811 | M-Series Loader | Fuel TemperatureExtremely High | ||||||
| M5811 | M-Series Excavator | Fuel Temperature Extremely High | ||||||
| M5815 | M-Series Loader | Fuel Temperature Shutdown | ||||||
| M5815 | M-Series Excavator | Fuel Temperature In Shutdown | ||||||
| M5815 | Telehandler | Fuel Temperature in shutdown | ||||||
| M5826 | M-Series Excavator | Fuel Temperature In Shutdown | ||||||
| M5826 | M-Series Loader | Fuel Temperature Pre Shutdown | ||||||
| M5902 | M-Series Loader | DPF Regeneration Switch Error On | ||||||
| M6002 | M-Series Loader | DPF Inhibit Regen Switch Error On | ||||||
| M6004 | Telehandler | Cab Controller No Communication | ||||||
| M6021 | M-Series Excavator | Left Control Switch Out of Range High | ||||||
| M6022 | M-Series Excavator | Left Control Switch Out of Range Low | ||||||
| M6024 | M-Series Excavator | Left Control Switch Out of Neutral | ||||||
| M6102 | M-Series Loader | Remote Parked Regeneration Switch Error On | ||||||
| M6105 | Telehandler | Safety Valve Short To Battery | ||||||
| M6106 | Telehandler | Safety Valve Short To Ground | ||||||
| M6107 | Telehandler | Safety Valve Open Circuit | ||||||
| M6121 | M-Series Excavator | Right Control Switch Out of Range High | ||||||
| M6122 | M-Series Excavator | Right Control Switch Out of Range Low | ||||||
| M6124 | M-Series Excavator | Right Control Switch Out of Neutral | ||||||
| M6132 | Telehandler | Safety Valve Overcurrent | ||||||
| M6202 | M-Series Loader | Tailgate Fan 1 Error On | ||||||
| M6203 | M-Series Loader | Tailgate Fan 1 Error Off | ||||||
| M6204 | M-Series Excavator | Load Moment Sensor In Error | ||||||
| M6221 | M-Series Excavator | Overload Warning Sensor Out of Range High | ||||||
| M6222 | M-Series Excavator | Overload Warning Sensor Out of Range Low | ||||||
| M6228 | M-Series Loader | Tailgate Fan 1 Failure | ||||||
| M6302 | M-Series Loader | Tailgate Fan 2 Error On | ||||||
| M6303 | M-Series Loader | Tailgate Fan 2 Error Off | ||||||
| M6328 | M-Series Loader | Tailgate Fan 2 Failure | ||||||
| M6402 | M-Series Loader | Switched Power Relay Error On | ||||||
| M6403 | M-Series Loader | Switched Power Relay Error Off | ||||||
| M6505 | M-Series Loader | ECU Power Short to Battery | ||||||
| M6505 | M-Series Excavator | ECU Power Short To Battery | ||||||
| M6506 | M-Series Loader | ECU Power Short to Ground | ||||||
| M6506 | M-Series Excavator | ECU Power Short To Ground | ||||||
| M6507 | M-Series Loader | ECU Power Open Circuit | ||||||
| M6604 | M-Series Loader | ECU No Communication | ||||||
| M6702 | M-Series Loader | HVAC Output Error On | ||||||
| M6703 | M-Series Loader | HVAC Output Error Off | ||||||
| Code | Product | Description | ||||||
| M6707 | M-Series Loader | HVAC Output Open Circuit | ||||||
| M6728 | M-Series Loader | HVAC Output Failure | ||||||
| M6802 | M-Series Loader | HVAC Relay Error On | ||||||
| M6803 | M-Series Loader | HVAC Relay Error Off | ||||||
| M6904 | M-Series Loader | DCU No Communication | ||||||
| M6905 | M-Series Excavator | Dump Valve Short to Battery | ||||||
| M6906 | M-Series Excavator | Dump Valve Short to Ground | ||||||
| M6907 | M-Series Excavator | Dump Valve Open Circuit | ||||||
| M6932 | M-Series Excavator | Dump Valve Overcurrent | ||||||
| M7002 | M-Series Loader | Switched Power Output Error On | ||||||
| M7003 | M-Series Loader | Switched Power Output Error Off | ||||||
| M7007 | M-Series Loader | Switched Power Output Open Circuit | ||||||
| M7028 | M-Series Loader | Switched Power Output Failure | ||||||
| M7102 | M-Series Loader | Electric Fan Output Error On | ||||||
| M7103 | M-Series Loader | Electric Fan Output Error Off | ||||||
| M7107 | M-Series Loader | Electric Fan Output Open Circuit | ||||||
| M7202 | M-Series Loader | Electric Fan Relay Error On | ||||||
