Kody diagnostyczne i serwisowe Bobcat - lista błędów i rozwiązań
Diagnostyka Bobcat - odczyt i interpretacja kodów usterek
Maszyny Bobcat wyposażone są w system elektroniczny, który monitoruje parametry pracy i zgłasza wszelkie nieprawidłowości w formie kodów błędów. Dzięki temu operator może szybko zidentyfikować problem i podjąć odpowiednie działania, aby uniknąć awarii lub dłuższego przestoju.
⚠️ Uwaga: Zanim przystąpisz do naprawy lub serwisu, zawsze skonsultuj się z Instrukcją Obsługi i Konserwacji swojej maszyny Bobcat.
Obsługiwane maszyny - zakres kodów diagnostycznych Bobcat:
Ładowarki serii M: od S450 do S850, od T450 do T870
Ładowarki serii R: od S60 do S70, od T60 do T70
Minikoparki serii M: od E26 do E85
Koparki E145 i E165
Ładowarki przegubowe kompaktowe (SAL)
Maszyny wielofunkcyjne Toolcat
Ładowarki kołowe kompaktowe
Ładowarki teleskopowe Bobcat
Osprzęt Bobcat
Diagnostyka silników Bobcat:
Silniki Bobcat V1 (ECU DELPHI)
Silniki Bobcat V2 (ECU BOSCH)
Silniki Bobcat D34 (DCU)
Specjalizujemy się w diagnostyce Bobcat, naprawach i optymalizacji pracy maszyn. Pomagamy zarówno w szybkim rozwiązywaniu problemów z kodami błędów, jak i w zapobieganiu przyszłym usterkom.
Bobcat Diagnostic Service Codes provide operators with a clear way to identify and troubleshoot machine issues. Covering loaders, excavators, telehandlers, and engines (Delphi, Bosch, DCU), these codes improve efficiency and minimize downtime. If you need help interpreting a fault code, our team can assist with diagnostics, repair, and machine optimization.
| Code | Product | Description | ||||||
| D7574 | M-Series Loader | Drive Right Wheel Speed Uncommanded Motion | ||||||
| D7575 | M-Series Loader | Drive Left Wheel Speed Uncommanded Motion | ||||||
| D7576 | M-Series Loader | Drive No Communication from ACS Controller | ||||||
| D7577 | M-Series Loader | Drive Left Speed Sensor Out of Range High | ||||||
| D7578 | M-Series Loader | Drive Right Speed Sensor Out of Range High | ||||||
| D7579 | M-Series Loader | Drive Left Speed Sensor Out of Range Low | ||||||
| D7580 | M-Series Loader | Drive Right Speed Sensor Out of Range Low | ||||||
| D7581 | M-Series Loader | Drive+ Right Front Steer Retract Short to Battery | ||||||
| D7582 | M-Series Loader | Drive+ Left Front Steer Retract Short to Battery | ||||||
| D7583 | M-Series Loader | Drive+ right Rear Steer Retract Short to Battery | ||||||
| D7584 | M-Series Loader | Drive+ Left Rear Steer Retract Short to Battery | ||||||
| D7585 | M-Series Loader | Drive 5 Volt Sensor Supply 1 Out of Range High | ||||||
| D7586 | M-Series Loader | Drive+ Sensor Supply 2 Out of Range High | ||||||
| Code | Product | Description | ||||||
| D7587 | M-Series Loader | Drive Software Update Required | ||||||
| D7588 | M-Series Loader | Drive/Drive+ Switched Power Stuck On | ||||||
| D7589 | M-Series Loader | Drive Switched Power Error Off | ||||||
| D7590 | M-Series Loader | Drive Drive calibration performed | ||||||
| D7591 | M-Series Loader | Drive Left Swashplate Sensor Reversed | ||||||
| D7592 | M-Series Loader | Drive Right Swashplate Sensor Reversed | ||||||
| D7593 | M-Series Loader | Drive Unresponsive Right Speed Sensor | ||||||
| D7594 | M-Series Loader | Drive Unresponsive Left Speed Sensor | ||||||
| D7595 | M-Series Loader | Drive Left Speed Sensor Reverse Direction | ||||||
| D7596 | M-Series Loader | Drive Right Speed Sensor Reverse Direction | ||||||
| D7597 | M-Series Loader | Drive Controller Programmed | ||||||
| D7598 | M-Series Loader | Drive Controller in Calibration Mode | ||||||
| D7599 | M-Series Loader | Drive Controller in Angle Calibration Mode | ||||||
| D7605 | Telehandler | Aux Female Output Short To Battery | ||||||
| D7606 | Telehandler | Aux Female Output Short To Ground | ||||||
| D7607 | Telehandler | Aux Female Output Open Circuit | ||||||
| D7632 | Telehandler | Aux Female Output Overcurrent | ||||||
| D7705 | Telehandler | Aux Male Output Short To Battery | ||||||
| D7706 | Telehandler | Aux Male Output Short To Ground | ||||||
| D7707 | Telehandler | Aux Male Output Open Circuit | ||||||
| D7732 | Telehandler | Aux Male Output Overcurrent | ||||||
| D7802 | Telehandler | DEF Tank Elec fan relay Error ON | ||||||
| D7803 | Telehandler | SCR Elec fan relay error OFF | ||||||
| D7902 | Telehandler | ACD Switches Error On | ||||||
| D8002 | Telehandler | Dump valve Short To Battery | ||||||
| D8003 | Telehandler | Dump valve Short To Ground | ||||||
| D8007 | Telehandler | Dump valve Open circuit | ||||||
| D8032 | Telehandler | Dump valve Overcurrent | ||||||
| D8110 | Telehandler | LS Pump Pressure High | ||||||
| D8121 | Telehandler | LS Pump Pressure Out of Range High | ||||||
| D8122 | Telehandler | LS Pump Pressure Out of Range Low | ||||||
| D8202 | Telehandler | Boom Suspension Valve Error On | ||||||
| D8203 | Telehandler | Boom Suspension Valve Error Off | ||||||
| D8207 | Telehandler | Boom Suspension Open Circuit | ||||||
| D8232 | Telehandler | Boom Suspension Overcurrent | ||||||
| D8302 | Telehandler | Stabilizers ON/OFF output valve Error On | ||||||
| D8303 | Telehandler | Stabilizers ON/OFF output valve Error Off | ||||||
| D8307 | Telehandler | Stabilizers ON/OFF output Open circuit | ||||||
| D8402 | Telehandler | Stabilizers ON/OFF Relay feedback Error On | ||||||
| D8403 | Telehandler | Stabilizers ON/OFF Relay feedback Error Off | ||||||
| D8505 | Telehandler | Stabilizers Left Up Output Short To Battery | ||||||
| D8506 | Telehandler | Stabilizers Left Up Output Short To Ground | ||||||
| D8507 | Telehandler | Stabilizers Left Up Output Open circuit | ||||||
| D8605 | Telehandler | Stabilizers Left Down Output Short To Battery | ||||||
| D8606 | Telehandler | Stabilizers Left Down Output Short To Ground | ||||||
| D8607 | Telehandler | Stabilizers Left Down Output Open circuit | ||||||
| D8705 | Telehandler | Stabilizers Right Up Output Short To Battery | ||||||
| D8706 | Telehandler | Stabilizers Right Up Output Short To Ground | ||||||
| D8707 | Telehandler | Stabilizers Right Up Output Open circuit | ||||||
| D8805 | Telehandler | Stabilizers Right Down Output Short To Battery | ||||||
| D8806 | Telehandler | Stabilizers Right Down Output Short To Ground | ||||||
| D8807 | Telehandler | Stabilizers Right Down Output Open circuit | ||||||
| Code | Product | Description | ||||||
| D8902 | Telehandler | Stabilizers Active Switch Error On | ||||||
| D9098 | Telehandler | Drive Controller Calibration Performed | ||||||
| D9099 | Telehandler | Drive Calibration Required | ||||||
| D9199 | Telehandler | Swash Plate Neutral range calibration required (drive pump) - See procedure | ||||||
| D9299 | Telehandler | Swash Plate maximal range calibration required (drive pump) - See procedure | ||||||
| D9302 | Telehandler | Trailer Brake Supplementary Line Output Error On | ||||||
| D9303 | Telehandler | Trailer Brake Supplementary Line Output Error Off | ||||||
| D9307 | Telehandler | Trailer Brake Supplementary Line Output Open Circuit | ||||||
| D9333 | Telehandler | Trailer Brake Supplementary Line Output Internal failure | ||||||
| D9402 | Telehandler | Trailer Brake Supplementary Line Relay Error On | ||||||
| D9403 | Telehandler | Trailer Brake Supplementary Line Relay Error Off | ||||||
| D9509 | Telehandler | Trailer Brake Reserve Pressure Low | ||||||
| D9605 | Telehandler | Redundancy Park Brake OutputShort To Battery | ||||||
| D9606 | Telehandler | Redundancy Park Brake OutputShort To Ground | ||||||
| D9607 | Telehandler | Redundancy Park Brake Output Open Cuircuit | ||||||
| D9999 | Telehandler | Bad constant Data Table | ||||||
